Overhaul Kit 32319667 IR 2540 Replacement
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
Overhaul Kit 32319667 IR 2540 Replacement
Ovewrhaul Kit for Ingersoll Rand Type 30 Air Compressor Model 2540 replacement from India.
Product
Overhaul Kit 32319667 IR 2540 Replacement
Contain of Kit
| No. | Description | Part No. | QTY |
| A | Bearing/Conn Rod Kit | 32204307 | -- |
| Crankpin Bushing | 30210165 | 1 | |
| Connecting Rod | 32198160 | 2 | |
| Ball Bearing | 95753604 | 2 | |
| Ball Bearing W/Snap Ring | 95951224 | 1 | |
| Inner Bearing Spacer | 32203218 | 1 | |
| B | Ring/Gasket Kit | 32198400 | -- |
| Gasket, Cover | 30280531 | 1 | |
| Oil Seal | 32204570 | 1 | |
| O-Ring | 95022158 | 1 | |
| Gasket, Cylinder Flange | 30294201 | 2 | |
| Manifold Gasket | 32188377 | 2 | |
| Frame End Cover Gasket | 32183956 | 1 | |
| Copper Gasket | 95674750 | 1 | |
| Ring Set | 32198335 | 1 | |
| Ring Set | 32198376 | 1 | |
| O-Ring | 95022695 | 1 | |
| C | Gasket Set | 32229890 | -- |
| L/P Valve Plate Gasket | 32233850 | 1 | |
| L/P Air Head Gasket | 32267494 | 1 | |
| Mainfold Gasket | 32188377 | 1 | |
| H/P Air Head Gasket | 32252777 | 1 | |
| H/P Valve Plate Gasket | 32252785 | 1 | |
| H/P Spacer Plate Gasket | 32252793 | 2 | |
| Flat washer | 32279408 | 4 | |
| Hex Cap Screw | 95104196 | 4 | |
| Cover Gasket | 30280531 | 1 | |
| Cylinder Flange Gasket | 30294201 | 2 | |
| Unloader Cover Gasket | 32182826 | 1 | |
| Frame End Cover Gasket | 32183956 | 1 | |
| Manifold Gasket | 32188377 | 2 | |
| Unloader Piston O-Ring | 32188385 | 1 | |
| O-Ring | 95022158 | 1 | |
| O-Ring | 95022695 | 1 | |
| D | Valve/Gasket Kit | 32229874 | -- |
| Finger Valve | 30220115 | 8 | |
| Disch Valve Plate | 30215917 | 1 | |
| Disch Valve Plate | 30215941 | 1 | |
| Disch Valve Spring | 30221394 | 2 | |
| Disch Valve Spring | 30221576 | 1 | |
| Unloader Cover Gasket | 32182826 | 1 | |
| Manifold Gasket | 32188377 | 2 | |
| LP Air Head Gasket | 32267494 | 1 | |
| LP Valve Plate Gasket | 32223850 | 1 | |
| Manifold Gasket | 32188377 | 1 | |
| H/P Airhead Gasket | 32252777 | 1 | |
| H/P Valve Plate Gasket | 32252785 | 1 | |
| H/P Spacer Plate Gasket | 32252793 | 2 | |
| Flat washer | 32279108 | 4 | |
| Hex Cap Screw | 95104196 | 4 | |
| Unloader Piston Seal | 32254740 | 1 | |
| Unloader Piston O-Ring | 32188385 | 1 | |
| Valve Retailer | 32228306 | 8 | |
| Valve Bolt | 32223927 | 2 | |
| Fillister Head Screw | 32035511 | 10 | |
| Washer | 32217382 | 8 | |
| Lock Washer | 95648150 | 2 | |
| Lock Nut | 32229684 | 1 | |
| Nut | 97166946 | 2 | |
| E | Air Filter Element | 32012957 | 1 |
| Total | 111 |
