Description

Intercooler Assembly For Ingersoll Rand Type 30 - Model 15T2

PFC - Parts for Compressor is a global supplier of OEM Quality New Aftermarket Replacement Air Compressor Spare Parts for - Intercooler Assembly For Ingersoll Rand Type 30 - Model 15T2 from India.

 View PDF

Product

  • Page 1

1. Intercooler Assembly

Sr.No Ref. Part Number Description
10-1 37131109 Assembly, Tube - Intercooler/3rd Stage
10-2 95031761 Elbow, Tube - 3/4 X 3/4
10-3 95083275 Connector, Tube 3/4 X 3/4
10-4 97048094 Valve, Safety - 60 PSIG
10-5 72062102 Valve, Safety - 260 PSIG
10-6 95736898 Gauge, Pressure -100 PSIG (32127896)
10-7 95736922 Gauge, Pressure -300 PSIG(32013898)
10-8 30282396 Damper Assembly - Pulsation
10-9 95110441 Elbow, Tube - 1/4
10-10 95006524 Tee, Pipe -1/4
10-11 95426714 Nipple, Close - 1/4 X 7/8
10-12 95053070 Capscrew - Hex 1/4-20 X 1/2
10-13 30218283 Shroud, Inter - Cooler, Bottom
10-14 30218275 Shroud, Inter - Cooler, Top
10-15 95053070 Capscrew-Hex 1/4-20 X 1/2
10-16 95094298 Washer, Flat - 1/4
10-17 95043196 Lockwasher, Spring - 1/4
10-18 30209829 Brace, Inter - Cooler Shroud
10-19 32024697 Tube Assembly, Finned -36"
10-20 32025678 Tube Assembly, Finned -38 - 3/4"
10-21 32025686 Tube Assembly, Finned -41 -1/2"
10-22 95083143 Connector, Male - 3/8 X 1/4"
10-23 95033338 Plug, Square Countersunk -1-1/4"
10-24 95033338 Plug, Square Countersunk -1
10-25 95043808 Capscrew-Hex 5/8-11 X 2-1/4
10-26 95002168 Capscrew-Hex 5/8-11 X 2-1/2
10-27 30345185 Washer, Flat - 5/8
10-28 37129038 Manifold, Intercooler
10-29 37129046 Manifold, Intercooler
10-30 30294870 Gasket, Manifold
10-31 30221121 Connection, Manifold

Details

  • type: product
  • SKU: 15T209
