Cylinder and Piston IR 7T2 Air Compressor Parts

availability: This product is not available in the selected currency.
  • Nothing

Description

Cylinder and Piston For Ingersoll Rand Type 30 Model 7T2

PFC - Parts for Compressor is a global supplier of OEM Quality New Aftermarket Replacement Air Compressor Spare Parts for - Cylinder and Piston For Ingersoll Rand Type 30 Model 7T2 from India.

 View PDF

Product

  • Page 1

2. Cylinder and Piston

Sr.No Ref. Part Number Description
2-1 32109779 Filter 10 Micron
2-2 37152196 Tube Assembly Intercooler/P.V
2-3 37152154 Tube Assembly Fec PV/Inlet/A/H
2-4 37152147 Tube Assembly Breather Frame/Inlet
2-5 30812028 Tube Intercooler Without Nut
2-6 95040184 Elbow Tube 1/2" od * 3/8 * NPT Male
2-7 95083184 Connector Tube 1/2" * 3/8" NPT
2-8 31385503 Valve Safety 1/2 X 600 PSIG
2-12 30666002 Valve Needle 1/4
2-13 32175051 Nipple Hex 1/4 WP 1000 PSIG
2-14 94495686 Leg Condensate Assembly
2-15 95033593 Plug Pipe Sq. HD.1/4"
2-16 94495694 Connection Air Outlet
2-17 95110441 Elbow Tube 5/16" OD * 1/4" NPT Male
2-18 95007522 Tee Tube 5/16" Tube X 18" NPT
2-19 95082491 Connector Tube 5/16" * 1/4" NPT
2-20 95110441 Elbow Tube 5/16" * 1/4" NPT Male
2-21 95053054 Screw Cap Hex 1/2" X 3"
2-22 37130481 Head Air Top AS & S
2-23 37004843 Valve Assembly 50
2-24 37007747 Gasket Air Head Center
2-25 37130499 Head Air Elbow 5"
2-26 37114030 Down Pin for Air Head
2-27 30294193 Gasket Air Head
2-28 95053567 Capscrew -Hex Head 1/2" X 1-1/4"
2-29 95674701 Washer Copper 1/2"
2-30 37128782 Cylinder LP 5" 15T
2-31 30294235 Gasket Cylinder Flange
2-32 30288450 Ring Lock
2-33 32054504 Piston Pin Assembly 5" LP
2-33A 30288427 Pin Piston
2-34 32198376 Ring Piston Set LP - 5" Dia. (32015174)
2-35 95104212 Screw Cap Hex 1/2" X 2-3/4"
2-36 37130655 Head Air 1-5/8"
2-37 31517725 Valve Complete 1-5/8"
2-38 30294284 Gasket Air Head
2-39 95053567 Screw Cap Hex Head 1/2" X 1-1/4"
2-40 95674701 Washer Copper 1/2"
2-41 37128519 Cylinder HP 2"
2-42 30294508 Gasket Air Head
2-43 95053567 Screw Cap Hex Head 1/2" X 1-1/4"
2-44 95674701 Washer Copper 1/2"
2-45 37128501 Cylinder HP 3-1/2"
2-46 30294235 Gasket Cylinder Flange
2-47 30288450 Ring Lock
2-48 32054538 Piston Pin Assembly 3"
2-48A 30288385 Pin Piston HP
2-49 37138088 Ring Piston Set 2"

Details

  • type: product
  • SKU: 7T202
