Drill Steel Support Comp. (32 mm) - Pneumatic Version

availability: This product is not available in the selected currency.

  • Nothing

Description

Drill Steel Support Comp with plate & bolt (32 mm) - Pneumatic Version

Vikay is a global supplier of new aftermarket replacement parts - Drill Steel Support Comp with plate & bolt (32 mm) - Pneumatic Version for Atlas Copco Wagon Drill Bvb-25 from India

View PDF

 Product

Drill Steel Support Comp with plate & bolt (32 mm) - Pneumatic Version

No. Description Modified   Ref. Part No. QTY
- Drill Steel Support (32mm) - Pneumatic Version     VK PDSX32 1
1 Bolt     M9062 8
2 Cover     M9063 2
3 O Ring 0663614800 * M9064 2
4 Screw     3142026400 2
5 O Ring     0663214900 2
6 Piston     M9067 2
7 O Ring 0663613500 * M9068 2
8 Nut     M9069 16
9 Seal Ring 0665919300 * M9070 2
10B Drill Steel Support Hal, 32 mm (11/4") Round 3142026200 * M9071 2
11 Cylinder     M9072 2
- Cylinder & Piston Complete Assembly     M9072 & 67 2
12 Drill Steel Support     M9073 1
13 Pressure Screw 0627511300 * M9074 2
14 Packing 0653107000 * M9075 4
15 Banjo Connection 9000029400 * M9076 2
16 Hose Clamp 0347610400 * M9077 2
17 -Air Hose 9030020000 * M9078 2
- Bushing For BSP-10     3142026100
- Piston For BSP-10     3142026300
- Lock Ring For BSP-10     0335217700
- Cover For BSP-10     3142026500

Details

  • type: product
  • SKU: VK PDSX32
